Powder Manufacturing Equipment Electrode Induction Melting Inert Gas Atomization EIGA

Brand Name : EasyFashion Industry

Model Number : /

Certification : CE/CB/CQC/FCC/ISO

Place of Origin : China

MOQ : 1 set

Price : /

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 15~25 sets per year

Delivery Time : 120~200 days

Packaging Details : 1.Outer package:Standard wooden cases 2.Inner package:Strenth films & Styrofoam

Commodity : Electrode Induction Gas Atomization EIGA Equipment

Raw material : high pure metal or alloy

Output product : ultrafine metal or alloy powder

Powder shape : spherical

feature : Low consumption

Contact Now

Electrode Induction Gas Atomization (EIGA) Equipment

1. Introduction

Under vacuum or inert gas protection, the slowly rotating feedstock rod is heated by high frequency induction coil and melted inductively and continuously in the absence of crucible. Then the molten falls free, flows into atomization system and is crushed into a large number of small liquid droplets by high pressure inert gas from atomizer spray plate. Then small liquid droplets are solidified into spherical granular powders in flight. Feedstock doesn’t contact with crucible and fluid limiting diversion tube, so it doesn’t get pollution.

It mainly consists of electrode induction melting furnace, atomizing system, atomizing tank,

powder collector, vacuum system, cooling system, gas system, high frequency power supply, etc.

2. Features and Structure

1. It can produce high melting and alive metal powders with spherical shape and ultra-high purity.

2. Low consumption

3. Alloy electrode is needed to be melted and electrode segregation results in uneven chemical composition of alloy powder.

3. Main technical parameters

Item	Specification
Total power	100KW
Melting capacity	5kg or 10kg (calculated by the density of Ti)
Feeding methods	single or continuous feeding by 10pcs each time
Feeding speed	rotation rate 1~30r/min; slow: 1~50mm/min (adjustable); fast: 200mm/min (constant).
Powder size	D50=45μm
Gas consumption	high pure Ar or nitrogen
