15 - Tube Reduction Furnace Six Heating Zones 460kw Fully Automatic Control

Name: 15 Tube Reduction Furnace Six Heating Zones 460kw Fully Automatic Control
Brand: EasyFashion
Price: 1 USD

Brand Name : EasyFashion

Model Number : 460kw

Certification : ISO9001:2008

Place of Origin : China

MOQ : 1 set

Price : To be discussed

Payment Terms : T/T, Western Union

Delivery Time : 15~25 sets per year

Packaging Details : standard packing, wooden cases

power capacity(kw) : 460kw

max.temperature : 1150

max.working temperature : 1050

heating zone number : six zones

output T/24h : 1.6T

Contact Now

15-Tube Reducing Furnace

Overview:

The equipment combines international and domestic practical situation on the basis of digesting and adopting overseas advanced equipment, researches and produces out multi-piping furnace for fitting the reduction of tungsten molybdenum.

Technical specifications:

Power capacity(kW)	460kW
Max. temperature (°C)	1150
Max. working temperature (°C)	1050
Heating zone number	Six zones
Types of push boat	Push boat pneumatically
Furnace piping dimension	Φ140 or Φ128 ×10000(mm)
Hydrogen circulation amount	450m³/h~900m³/h
Output T/24h	1.6 T
Furnace weight (kg)	About 35000 kg
Dimension(mm)	17100×3000×2190

Features:

1. Wide applications and fully automatic control.

2. Uniform furnace temperature, small fluctuation range, reliable control preision.

3. Output powder granularity is uniform and the distributing range is narrow.

4. Reasonable equipment structure, adopts new energy-saving type brasque.
