Magnetic Powder Metallurgy Manufacturing Process For Amorphous Alloy Powder Production

200 KG Fast Amorphous Alloy Powder Production Equipment For Iron Base Nanometer Material

Overview

Amorphous Alloy Powder Production Equipment is the magnetic material processing equipment that continuously produces amorphous alloy powders by using high-speed cooling method. The large-scale production is conducted under protective gas or vacuum condition. The produced powders are mainly used for electrics, electronic components, military industry etc..

Specifications

• High-frequency output: 5kW;
• Smelting capacity: 5~50g/based on iron;
• Cooling roller rotating speed: 100-500rpm (single roller size: Φ200*20mm);
• Vacuum reaching pressure: 10^-3 Pa (when filling with specimen and nozzle);
• Highest heating temperature: 1500°C;
• Leakage volume: less than 10^-9Pam³/sec;
• Output frequency: 100KHz.
• Injection pressure: max. 0.1MPa;
• Common heating temperature: 1200°C;
• Power supply: 3 phases, 220V, 13KVA (clients need to prepare voltage transformer for their own)
• Cooling water: 25L/min, water pressure: 0.35MPa (backpressure: less than 0.1MPa)

Inert gas (Ar): displaced capacity 100L/per time, pressure 0.5MPa.

Features

Its working principle refers to that smelted metal is jetted onto quench cooling roller in high-speed rotation under given conditions in Ar gas environment after vacuum exhausting, and then the amorphous thin band is formed though quench cooling process.
