Industrial Vacuum Heat Treatment Furnace High Thermal Efficiency For Copper Material

Name: Industrial Vacuum Heat Treatment Furnace High Thermal Efficiency For Copper Material
Brand: EasyFashion Industry
Price: 1 USD

Brand Name : EasyFashion Industry

Model Number : EFZK-QH-200

Certification : CE Certificate

Place of Origin : China

MOQ : 1 set

Supply Ability : 10 set per year

Delivery Time : 120 days

Packaging Details : Standard packed by wooden cases and container.

Rated loading capacity (kg) : 200

Max. furnace temperature (°C) : 1350

Rated power(kW) : 120

Working zone size (mm) : 450*400*670

Gas cooling pressure (Mpa) : ≤0.1Mpa

Configuration of vacuum system : Rotary vane pump+ Roots pump

Contact Now

High Thermal Efficiency Small Area Vacuum Brazing Furnace With Copper For Brazing Of Parts

I. Overview
Vacuum brazing furnace is principally adopted in Al brazing, Cu brazing and stainless-steel brazing of aerospace devices, vehicle components, home appliances, heat exchanger and various heat radiators.

II.Technical specifications

Specification/ Model	EFZK-QH-50	EFZK-QH-100		EFZK-QH-200		EFZK-QH-300		EFZK-QH-400
Rated loading capacity (kg)	50	100		200		300		400

Max. furnace temperature (°C)	1350
Temperature controlling precision (°C)	≤±5
Rated power(kW)	50	90	120		150		180
Rated supply voltage (V)	380
Ultimate vacuum degree (Pa)	≤6.67 (empty furnace in cold status)
Gas cooling pressure (Mpa)	≤0.1Mpa
Configuration of temperature controlling system	Programmable regulator of Japan SHIMADEN
Configuration of vacuum system	Rotary vane pump+ Roots pump
Note: The above is standard configuration which is adjustable based on customer requirements.

III. Features
1. Heating chamber of this vacuum brazing furnace is fitted with temperature control deployed in several zones. Hence, outstanding heat uniformity is aggressively guaranteed.
2. Single chamber, interior heating, cool wall, vertical and horizontal layout are all available with compacted structure. Customers avail from various choices to fit their specific application needs.
3. Well-conceived thermal insulation shield is available in this vacuum brazing furnace, whereby promoting heat efficiency.
4. Vacuum system of this vacuum brazing furnace comes with specialized condensation filter to eliminate pollution that brazing flux vapor brings to vacuum pump.

Product Tags:

high temperature vacuum furnace

high temperature sintering furnace

Quality Industrial Vacuum Heat Treatment Furnace High Thermal Efficiency For Copper Material wholesale

Industrial Vacuum Heat Treatment Furnace High Thermal Efficiency For Copper Material Images
