Auto Parts Vacuum Brazing Furnace , High Temperature Vacuum Furnace Brazing Process

Name: Auto Parts Vacuum Brazing Furnace High Temperature Vacuum Furnace Brazing Process
Brand: EasyFashion Industry
Price: 1 USD

Brand Name : EasyFashion Industry

Model Number : EFZK-QH-100

Certification : CE Certificate

Place of Origin : China

MOQ : 1 set

Supply Ability : 10 set per year

Delivery Time : 120 days

Packaging Details : Standard packed by wooden cases and container.

Rated loading capacity (kg) : 100

Max. furnace temperature (°C) : 1350

Rated power(kW) : 90

Working zone size (mm) : 300*300*500

Ultimate vacuum degree (Pa) : ≤6.67 (empty furnace in cold status)

Vacuum pressure rising rate (Pa/24h) : ≤50

Contact Now

Auto Parts Vacuum Brazing Furnace , High Temperature Vacuum Furnace Brazing Process

Product Description

1. Usage

The vacuum brazing furnace is mainly applicable for brazing of aluminum, copper and stainless steel used for parts of airplane, automobile, electronic communication equipment, household appliance, heat exchanger and radiator, etc. Heating in vacuum environment removes grease and oxidation on surfaces of workpiece. Therefore, output products that our industrial furnace generates are endowed with brilliant surfaces, requiring no brazing flux or washing.

Related Names: Brazing Machine | Copper Brazing Furnace | Vacuum Furnace

2. Features

1. Single chamber, interior heating, cool wall, vertical and horizontal layout are all available with compacted structure. Customers avail from various choices to fit their specific application needs.

2. Heating chamber of this copper brazing furnace is fitted with temperature control deployed in several zones. Hence, outstanding heat uniformity is aggressively guaranteed.

3. Well-conceived thermal insulation shield is available in our atmosphere brazing furnace, whereby promoting heat efficiency.

4. Vacuum system of this single chamber vacuum brazing furnace comes with specialized condensation filter to eliminate pollution that brazing flux vapor brings to vacuum pump.

3. Technical Parameters

Specification/ Model	EFZK-QH-50	EFZK-QH-100		EFZK-QH-200		EFZK-QH-300		EFZK-QH-400
Rated loading capacity (kg)	50	100		200		300		400

Max. furnace temperature (°C)	1350
Temperature controlling precision (°C)	≤±5
Rated power(kW)	50	90	120		150		180
Rated supply voltage (V)	380
Rated heating voltage (V)	Based on design. Furnace-front transformer is equipped.
Ultimate vacuum degree (Pa)	≤6.67 (empty furnace in cold status)
Vacuum pressure rising rate (Pa/24h)	≤50
Gas cooling pressure (Mpa)	≤0.1Mpa
Working zone size (mm)	300300400	300300500	450400670		450400850		6006001000

Configuration of temperature controlling system	Programmable regulator of Japan SHIMADEN
Configuration of vacuum system	Rotary vane pump+ Roots pump
Note: The above is standard configuration which is adjustable based on customer requirements.

Company Information

Easyfashion Industry is a comprehensive product supplier with many joint ventures and cooperative enterprises, specializing in designing, manufacturing, and selling various kinds of industrial furnaces,such as heat treatment machines , material heat treatment machines and so on. Our company has many advanced powder and metallurgy products manufacturing and melting technology, specially with abundant technical foundations and production experiences of smelting and advanced material production equipments.
