Hot Isostatic Pressing Vacuum Heat Treatment Furnace 100Mpa For Auto Parts

Name: Hot Isostatic Pressing Vacuum Heat Treatment Furnace 100Mpa For Auto Parts
Brand: EasyFashion Industry
Price: 1 USD

Brand Name : EasyFashion Industry

Model Number : EF-T

Certification : CE Certificate

Place of Origin : China

MOQ : 1 set

Supply Ability : 10 set per year

Delivery Time : 120 days

Packaging Details : Standard packed by wooden cases and container.

Hot zone (mm) : Φ125*200

Max. working temperature (°C) : 2000

Atmosphere : Ar

Heating element : Graphite

Contact Now

Hot Isostatic Pressing Furnace

Overview

HIP (Hot Isostatic Pressing) is an advanced sintering technology and combines debinding, sintering and densification into an integrated cycle. Identical pressure is carried on specimen under high temperature and high pressure. It results in a product that contains little or no porosity, thereby producing a component that is as close to full theoretical density as possible.

Specifications

Model	Hot zone (mm)	Max. working temperature (°C)	Working pressure (Mpa)	Heating element	Atmosphere
EF-R	Φ500*500	900	60	Cr20Ni80	Ar
EF-S	Φ150*300	1450	100	Molybdenum	Ar
EF-T	Φ125*200	2000	120	Graphite	Ar
Note: Custom furnace available upon request.

Features

1. High density and high uniformity

2. Short production cycle and low energy consumption

3. Outstanding properties
