10-300kg capacity spherical titanium metal powder gas atomization equipment
1. Equipment application
Metal powder gas atomizer equipment is melting titanium in vacuum conditions ,then the melting metal liquid go through insulation crucible, diversion from the mouth (down), the metal liquid will be atomizing and breaking into droplets of many small and thin droplet through the nozzle by high-pressure air, the droplet will be solidified into aspherical or spherical particles in flight, achieve the purpose of flour.
2. Equipment parts
(1)vacuum melting furnace
(2)holding furnace
(3)atomization chamber
(4)dust cleaner
(5)powder collection chamber
(6) Equipment platform
3. Capacity
According to your demands, 10KG~300KG/furnace.The titanium gas atomization equipment is used to make titanium powder using in 3D printing powder etc.
Specifications
| Model |
EFSWH-30 |
EFSWH-50 |
EFSWH-100 |
EFSWH-300 |
EFSWH-500 |
EFSWH-1000 |
|
High-pressure water pressure
(MPa)
|
30~120 |
| High-pressure water flow (L/min) |
50~800 |
| Furnace weight (kg) |
30 |
50 |
100 |
300 |
500 |
1000 |
| Highest melting temperature°C |
1750 |
| Melt heating power (kW) |
50 |
100 |
160 |
300 |
400 |
600 |
| Temperature measuring method |
Infrared thermometer, WRe5.26 |
| Tundish heating power (kW) |
20~45 |
| Power supply |
3 phases, 380V, 50Hz |
| Installed total power (kW) |
Based on different capacity and configuration |
| Cooling water flow (L/min) |
150 |
300 |
400 |
700 |
| Cooling water device |
Fan cooling tower, water cooling unit, heat exchanger |
| Soft water flow (m3/h) |
6~20 |
| Control mode |
Industrial control computer or PLC |
| Operation interface |
Touch-tone or Touch-screen |
| Data recording |
12 data-curve recording, LCD monitoring display |
|
Appearance size
(LxWxH) (mm)
|
7500x
4000x6500
|
7500x
4200x6500
|
8200x
5200x6500
|
9200x6500x6500 |
9500x6500x6500 |
10000x7000x6500 |
FAQ
1. How can I know your factory can produce equipment I need?
Re: Contact us and let us know your requirements of equipment. Then we will send these requirements to our technical department. So we will know whether our factory can offer you equipment or not.
2. Does your company customize equipment for customer?
Re: Yes, we can customize equipment according to customers' requirements.
3. How can I believe your quality?
Our equipment are eqquiped with mechanical parts of world renowned brands like Schneider, Omron and so on, and also approved ISO9001 certification.
